CoreUI PRO Component

To use this component you must have a CoreUI PRO license. Buy the CoreUI PRO and get access to all PRO components, features, templates, and dedicated support.

Alpha release

This component is in the Alpha phase and has an experimental API, which can be changed in the final release. If you want to use this component, please install @coreui/coreui-pro v5.1.0-alpha.0

Bootstrap 5 Rating

Rating

The Rating component allows users to provide feedback on content or services by selecting a rating value. It is customizable, supports various sizes and icons, and can be made interactive or read-only.

On this page

How to use Rating Component.

Embed the Rating component in your HTML by using a div with data-coreui-toggle="rating". Set the initial value with data-coreui-value.

html

<div data-coreui-toggle="rating" data-coreui-value="3"></div>

Allow clear

Enable users to clear their selected rating by clicking on the current rating again. This functionality is activated by setting data-coreui-allow-clear="true".

html

<div data-coreui-allow-clear="true" data-coreui-toggle="rating" data-coreui-value="3"></div>

This allows the selected rating to be deselected, effectively resetting the rating to a state where no value is selected.

Readonly

Set the Rating component to read-only by adding data-coreui-read-only="true". This disables interaction, preventing users from changing the displayed rating value.

html

<div data-coreui-read-only="true" data-coreui-toggle="rating" data-coreui-value="3"></div>

Disabled

Add the data-coreui-disabled="true" boolean attribute to give it a grayed out appearance, remove pointer events, and prevent focusing.

html

<div data-coreui-disabled="true" data-coreui-toggle="rating" data-coreui-value="3"></div>

Precision

Adjust the granularity of the Rating component by setting data-coreui-precision. This attribute allows for fractional ratings, such as quarter values, to provide more precise feedback.

html

<div data-coreui-precision="0.25" data-coreui-toggle="rating" data-coreui-value="1.5"></div>

Number of items

Control the total number of rating items displayed by using data-coreui-max. You can create a Rating component with a custom scale, be it larger for detailed assessments or smaller for simplicity.

html

<div data-coreui-max="20" data-coreui-toggle="rating" data-coreui-value="5"></div>

html

<div data-coreui-max="3" data-coreui-toggle="rating" data-coreui-value="1"></div>

Tooltips

Enable descriptive text on hover by setting data-coreui-tooltips to true. This provides immediate feedback or guidance as the user interacts with the rating items.

html

<div data-coreui-toggle="rating" data-coreui-tooltips="true" data-coreui-value="3"></div>

For custom messages, provide a comma-separated list of tooltips corresponding to each rating value to enhance the user’s understanding of each rating level.

html

<div data-coreui-toggle="rating" data-coreui-tooltips="Very bad, Bad, Meh, Good, Very good" data-coreui-value="3"></div>

Sizes

Larger or smaller rating component? Add data-coreui-size="lg" or data-coreui-size="sm" for additional sizes.

html

<div data-coreui-size="sm" data-coreui-toggle="rating" data-coreui-value="3"></div>
<div data-coreui-toggle="rating" data-coreui-value="3"></div>
<div data-coreui-size="lg" data-coreui-toggle="rating" data-coreui-value="3"></div>

Custom icons

Customize the Rating component with your choice of SVG icons by assigning new values to the activeIcon and icon properties in the JavaScript options. This allows for a unique look tailored to the design language of your site or application.

The Rating component can be customized with either SVG or font icons, allowing for visual alignment with your application’s design. You can specify different icons for each rating value to enhance user interaction.

In the example below, we demonstrate how to set custom icons using SVG, allowing for detailed customization of the visual elements within the Rating component.

html

<div id="myRatingCustomIcons1"></div>

docs/assets/js/snippets.js

const myRatingCustomIcons1 = document.getElementById('myRatingCustomIcons1')
if (myRatingCustomIcons1) {
  const optionsCustomIcons1 = {
    activeIcon: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512"><path fill="currentColor" d="M470.935,194.043,333.8,171.757,270.227,48.22a16,16,0,0,0-28.454,0L178.2,171.757,41.065,194.043A16,16,0,0,0,32.273,221.1l97.845,98.636L108.936,457.051a16,16,0,0,0,23.02,16.724L256,411.2l124.044,62.576a16,16,0,0,0,23.02-16.724L381.882,319.74,479.727,221.1A16,16,0,0,0,470.935,194.043Z"/></svg>',
    icon: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512"><path fill="currentColor" d="M494,198.671a40.536,40.536,0,0,0-32.174-27.592L345.917,152.242,292.185,47.828a40.7,40.7,0,0,0-72.37,0L166.083,152.242,50.176,171.079a40.7,40.7,0,0,0-22.364,68.827l82.7,83.368-17.9,116.055a40.672,40.672,0,0,0,58.548,42.538L256,428.977l104.843,52.89a40.69,40.69,0,0,0,58.548-42.538l-17.9-116.055,82.7-83.368A40.538,40.538,0,0,0,494,198.671Zm-32.53,18.7L367.4,312.2l20.364,132.01a8.671,8.671,0,0,1-12.509,9.088L256,393.136,136.744,453.3a8.671,8.671,0,0,1-12.509-9.088L144.6,312.2,50.531,217.37a8.7,8.7,0,0,1,4.778-14.706L187.15,181.238,248.269,62.471a8.694,8.694,0,0,1,15.462,0L324.85,181.238l131.841,21.426A8.7,8.7,0,0,1,461.469,217.37Z"/></svg>',
    value: 3
  }
  new coreui.Rating(myRatingCustomIcons1, optionsCustomIcons1)
}

In the example below, we use font icons from the CoreUI Icons set. In the activeIcon configuration, we also apply the utility class text-danger to change the icon’s color to red when it is active.

html

<div id="myRatingCustomIcons2"></div>

docs/assets/js/snippets.js

const myRatingCustomIcons2 = document.getElementById('myRatingCustomIcons2')
if (myRatingCustomIcons2) {
  const optionsCustomIcons2 = {
    activeIcon: '<i class="cil-heart text-danger"></i>',
    icon: '<i class="cil-heart"></i>',
    value: 3
  }
  new coreui.Rating(myRatingCustomIcons2, optionsCustomIcons2)
}

For a more dynamic experience, define different icons for each rating value, enhancing the visual feedback:

html

<div id="myRatingCustomIcons3"></div>

docs/assets/js/snippets.js

const myRatingCustomIcons3 = document.getElementById('myRatingCustomIcons3')
if (myRatingCustomIcons3) {
  const optionsCustomIcons3 = {
    activeIcon: {
      1: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" class="text-danger-emphasis" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><path fill="var(--ci-primary-color, currentColor)" d="M256,280A104,104,0,0,0,152,384H360A104,104,0,0,0,256,280Z" class="ci-primary"></path><rect width="32.001" height="96.333" x="148" y="159.834" fill="var(--ci-primary-color, currentColor)" class="ci-primary" transform="rotate(-48.366 164.002 208.001)"></rect><rect width="96.333" height="32" x="291.834" y="192" fill="var(--ci-primary-color, currentColor)" class="ci-primary" transform="rotate(-48.366 340.002 208)"></rect></svg>',
      2: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" class="text-danger" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><rect width="40" height="40" x="152" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="40" height="40" x="320" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><path fill="var(--ci-primary-color, currentColor)" d="M256,280A104,104,0,0,0,152,384H360A104,104,0,0,0,256,280Z" class="ci-primary"></path></svg>',
      3: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" class="text-warning" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><rect width="40" height="40" x="152" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="40" height="40" x="320" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="176" height="32" x="168" y="320" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect></svg>',
      4: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" class="text-success" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><rect width="40" height="40" x="152" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="40" height="40" x="320" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><path fill="var(--ci-primary-color, currentColor)" d="M256,384A104,104,0,0,0,360,280H152A104,104,0,0,0,256,384Z" class="ci-primary"></path></svg>',
      5: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" class="text-success-emphasis" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><path fill="var(--ci-primary-color, currentColor)" d="M256,384A104,104,0,0,0,360,280H152A104,104,0,0,0,256,384Z" class="ci-primary"></path><polygon fill="var(--ci-primary-color, currentColor)" points="205.757 228.292 226.243 203.708 168 155.173 109.757 203.708 130.243 228.292 168 196.827 205.757 228.292" class="ci-primary"></polygon><polygon fill="var(--ci-primary-color, currentColor)" points="285.757 203.708 306.243 228.292 344 196.827 381.757 228.292 402.243 203.708 344 155.173 285.757 203.708" class="ci-primary"></polygon></svg>'
    },
    icon: {
      1: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><path fill="var(--ci-primary-color, currentColor)" d="M256,280A104,104,0,0,0,152,384H360A104,104,0,0,0,256,280Z" class="ci-primary"></path><rect width="32.001" height="96.333" x="148" y="159.834" fill="var(--ci-primary-color, currentColor)" class="ci-primary" transform="rotate(-48.366 164.002 208.001)"></rect><rect width="96.333" height="32" x="291.834" y="192" fill="var(--ci-primary-color, currentColor)" class="ci-primary" transform="rotate(-48.366 340.002 208)"></rect></svg>',
      2: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><rect width="40" height="40" x="152" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="40" height="40" x="320" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><path fill="var(--ci-primary-color, currentColor)" d="M256,280A104,104,0,0,0,152,384H360A104,104,0,0,0,256,280Z" class="ci-primary"></path></svg>',
      3: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><rect width="40" height="40" x="152" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="40" height="40" x="320" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="176" height="32" x="168" y="320" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect></svg>',
      4: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><rect width="40" height="40" x="152" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><rect width="40" height="40" x="320" y="200" fill="var(--ci-primary-color, currentColor)" class="ci-primary"></rect><path fill="var(--ci-primary-color, currentColor)" d="M256,384A104,104,0,0,0,360,280H152A104,104,0,0,0,256,384Z" class="ci-primary"></path></svg>',
      5: '<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 512 512" role="img" aria-hidden="true"><path fill="var(--ci-primary-color, currentColor)" d="M256,16C123.452,16,16,123.452,16,256S123.452,496,256,496,496,388.548,496,256,388.548,16,256,16ZM403.078,403.078a207.253,207.253,0,1,1,44.589-66.125A207.332,207.332,0,0,1,403.078,403.078Z" class="ci-primary"></path><path fill="var(--ci-primary-color, currentColor)" d="M256,384A104,104,0,0,0,360,280H152A104,104,0,0,0,256,384Z" class="ci-primary"></path><polygon fill="var(--ci-primary-color, currentColor)" points="205.757 228.292 226.243 203.708 168 155.173 109.757 203.708 130.243 228.292 168 196.827 205.757 228.292" class="ci-primary"></polygon><polygon fill="var(--ci-primary-color, currentColor)" points="285.757 203.708 306.243 228.292 344 196.827 381.757 228.292 402.243 203.708 344 155.173 285.757 203.708" class="ci-primary"></polygon></svg>'
    },
    highlightOnlySelected: true,
    tooltips: ['Very bad', 'Bad', 'Meh', 'Good', 'Very good'],
    value: 3
  }
  new coreui.Rating(myRatingCustomIcons3, optionsCustomIcons3)
}

Heads up! In our documentation, all examples show standard CoreUI implementation. If you are using a Bootstrap-compatible version of CoreUI, remember to use the following changes:

In the constructor, please use bootstrap instead of coreui. For example, new bootstrap.Alert(...) instead of new coreui.Alert(...)
In events, please use bs instead of coreui, for example close.bs.alert instead of close.coreui.alert
In data attributes, please use bs instead of coreui. For example, data-bs-toggle="..." instead of data-coreui-toggle="..."

Usage

Via data attributes

Add data-coreui-toggle="rating" to a div element.

<div data-coreui-toggle="rating"></div>

Via JavaScript

Call the rating component via JavaScript:

<div class="rating"></div>

const ratingElementList = Array.prototype.slice.call(document.querySelectorAll('.rating'))
const ratingList = ratingElementList.map(ratingEl => {
  return new coreui.Rating(ratingEl)
})

Options

As options can be passed via data attributes or JavaScript, you can append an option name to data-coreui-, as in data-coreui-animation="{value}". Make sure to change the case type of the option name from “camelCase” to “kebab-case” when passing the options via data attributes. For example, use data-coreui-custom-class="beautifier" instead of data-coreui-customClass="beautifier".

As of CoreUI 4.2.0, all components support an experimental reserved data attribute data-coreui-config that can house simple component configuration as a JSON string. When an element has data-coreui-config='{"delay":0, "title":123}' and data-coreui-title="456" attributes, the final title value will be 456 and the separate data attributes will override values given on data-coreui-config. In addition, existing data attributes are able to house JSON values like data-coreui-delay='{"show":0,"hide":150}'.

Name	Type	Default	Description
`activeIcon`	object \| string \| null	`null`	The default icon to display when the item is selected.
`allowClear`	boolean	`false`	Enables the clearing upon clicking the selected item again.
`disabled`	boolean	`false`	Toggle the disabled state for the component.
`highlightOnlySelected`	boolean	`false`	If enabled, only the currently selected icon will be visibly highlighted.
`icon`	object \| string \| null	`null`	The default icon to display when the item is not selected.
`max`	number	`5`	The maximum value the user can select.
`name`	string	`null`	The name attribute of the radio input elements.
`precision`	number	`1`	Minimum increment value change allowed.
`readOnly`	boolean	`false`	Toggle the readonly state for the component.
`size`	`'sm'` \| `'lg'`	`null`	Size the component small or large.
`tooltips`	array \| boolean \| object	`false`	Enable tooltips with default values or set specific labels for each icon.
`value`	number \| null	`null`	The default `value` of component.

Methods

Method	Description
`update`	Updates the configuration of the rating.
`dispose`	Destroys a component. (Removes stored data on the DOM element)
`getInstance`	Static method which allows you to get the rating instance associated to a DOM element, you can use it like this: `coreui.Rating.getInstance(element)`
`getOrCreateInstance`	Static method which returns a rating instance associated to a DOM element or create a new one in case it wasn’t initialized. You can use it like this: `coreui.Rating.getOrCreateInstance(element)`

Events

Method	Description
`change.coreui.rating`	Callback fired when the selected item changed.
`mouseenter.coreui.rating`	The callback fired when the cursor entered the item.
`mouseleave.coreui.rating`	The callback fired when the cursor leave the item.

const myRating = document.getElementById('myRating')
myRating.addEventListener('change.coreui.rating', event => {
  // do something...
})

Customizing

CSS variables

Ratings use local CSS variables on .rating for enhanced real-time customization. Values for the CSS variables are set via Sass, so Sass customization is still supported, too.

scss/_rating.scss

--#{$prefix}rating-gap: #{$rating-gap};
--#{$prefix}rating-transition: #{$rating-transition};
--#{$prefix}rating-item-height: #{$rating-item-height};
--#{$prefix}rating-item-color: #{$rating-item-color};
--#{$prefix}rating-item-scale-transform: #{$rating-item-scale-transform};
--#{$prefix}rating-item-active-color: #{$rating-item-active-color};
--#{$prefix}rating-item-icon: #{escape-svg($rating-item-icon)};

SASS variables

scss/_variables.scss

$rating-gap:                   .0625rem;
$rating-transition:            color .15s ease-out, transform .15s ease-out;
$rating-item-height-sm:        1rem;
$rating-item-height:           1.25rem;
$rating-item-height-lg:        1.5rem;
$rating-item-color:            var(--#{$prefix}tertiary-color);
$rating-item-scale-transform:  scale(1.2);
$rating-item-active-color:     var(--#{$prefix}warning);
